W Beam
W beams are a type of hot-rolled steel beam that is shaped like a capital letter “W”. They are commonly used in construction and engineering applications due to their high strength and durability.
Product Description
W beams are a type of hot-rolled steel beam that is shaped like a capital letter “W”. They are commonly used in construction and engineering applications due to their high strength and durability. The unique shape of W beams allows them to distribute weight evenly across their length, making them ideal for use in load-bearing structures such as bridges, buildings, and industrial facilities. Additionally, W beams can be easily customized to meet specific design requirements, making them a versatile option for a wide range of projects. One advantage of W beams is that the flanges are thicker than the web. This contributes to the resistance to bending stress.
|
W Profile Sizes |
||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Imperial (inch) | Size (mm) | G kg/m |
A mm |
b mm |
h mm |
tw mm |
tf mm |
|||||||||||
| W 6x4x7 | W 150x100x10.4 | 10,4 | 7,6 | 99,2 | 147,1 | 3,4 | 4,1 | |||||||||||
| W 6x4x7,75 | W 150x100x11.5 | 11,5 | 12,3 | 99,6 | 147,8 | 3,8 | 4,5 | |||||||||||
| W 6x4x8,5 | W 150x100x12.6 | 12,6 | 15,9 | 100,1 | 148,1 | 4,3 | 5,0 | |||||||||||
| W 6x4x9 | W 150x100x13.4 | 13,4 | 17,3 | 100,1 | 150,0 | 4,3 | 5,5 | |||||||||||
| W 6x4x10,4 | W 150x100x15.5 | 15,5 | 19,6 | 100,8 | 151,4 | 5,1 | 6,3 | |||||||||||
| W 6x4x12 | W 150x100x17.9 | 17,9 | 22,9 | 101,6 | 153,2 | 5,8 | 7,1 | |||||||||||
| W 6x4x16 | W 150x100x23.8 | 23,8 | 30,6 | 102,4 | 159,5 | 6,6 | 10,3 | |||||||||||
| W 8x4x10 | W 200x100x14.9 | 14,9 | 19,1 | 100,0 | 200,0 | 4,3 | 5,2 | |||||||||||
| W 8x4x13 | W 200x100x19.3 | 19,3 | 24,8 | 102,0 | 203,0 | 5,8 | 6,5 | |||||||||||
| W 8x4x15 | W 200x100x22.5 | 22,5 | 28,6 | 102,0 | 206,0 | 6,2 | 8,0 | |||||||||||
| W 8×5,25×14 | W 200x130x21.4 | 21,4 | 27,2 | 134,0 | 203,0 | 5,0 | 6,4 | |||||||||||
| W 8×5,25×18 | W 200x130x26.6 | 26,6 | 33,9 | 133,0 | 207,0 | 5,8 | 8,4 | |||||||||||
| W 8×5,25×21 | W 210x130x31.3 | 31,3 | 40,0 | 134,0 | 210,0 | 6,4 | 10,2 | |||||||||||
